An END-TO-END Guide on Portable CO2 Fire Extinguisher
When it comes to a fire extinguisher, a CO2 portable fire extinguisher is one of the most common types that you will find everywhere. Furthermore, these are created to prevent fire caused by burning natural materials, such as wood or paper. Likewise, the CO2 can be used in two forms: dry and wet powder. However, it is highly effective when used in its liquid form. Do you know? Carbon dioxide is an odorless and colorless gas that is heavier than air.
Nevertheless, when it comes to commercial or residential fire protection, extinguishers are a vital component for the security of your building, employees, coworkers, and family members. Apart from this, selecting the right CO2 portable fire extinguisher for the circumstance is a more significant element that every individual should consider. When you use a fire extinguisher appropriately, it will function quickly and effectively in preventing small fires that do not need a massive amount of water to extinguish them. Therefore, in this comprehensive. We will discuss all aspects of the fire extinguisher in a single blog post.
Technical Configuration of CO2 Fire Extinguishers As Per Their Sizes
1. 2 kg CO2 Fire Extinguisher
| Specification | Details |
|---|---|
| Capacity | 2 kg |
| Fire Rating | 21B / C |
| Cylinder Material | Seamless Mild Steel or Aluminium |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 8–10 seconds |
| Discharge Range | 2–3 meters |
| Approx. Weight (Charged) | ~6–7 kg |
| Applications | Small offices, labs, vehicles |
2. 3 kg CO2 Fire Extinguisher
| Specification | Details |
|---|---|
| Capacity | 3 kg |
| Fire Rating | 34B / C |
| Cylinder Material | Seamless Mild Steel or Aluminium |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 12–15 seconds |
| Discharge Range | 2–4 meters |
| Approx. Weight (Charged) | ~9–10 kg |
| Applications | Computer rooms, small server areas |
3. 4.5 kg CO2 Fire Extinguisher
| Specification | Details |
|---|---|
| Capacity | 4.5 kg |
| Fire Rating | 55B / C |
| Cylinder Material | Seamless Mild Steel or Aluminium |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 15–20 seconds |
| Discharge Range | 2–5 meters |
| Approx. Weight (Charged) | ~13–15 kg |
| Applications | Industrial workshops, medium server rooms |
4. 6.5 kg CO2 Fire Extinguisher
| Specification | Details |
|---|---|
| Capacity | 6.5 kg |
| Fire Rating | 89B / C |
| Cylinder Material | Seamless Mild Steel or Aluminium |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 20–25 seconds |
| Discharge Range | 2–6 meters |
| Approx. Weight (Charged) | ~20–22 kg |
| Applications | Large offices, warehouses, and electrical rooms |
5. 9 kg CO2 Fire Extinguisher
| Specification | Details |
|---|---|
| Capacity | 9 kg |
| Fire Rating | 144B / C |
| Cylinder Material | Seamless Mild Steel or Aluminium |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 25–30 seconds |
| Discharge Range | 2–6 meters |
| Approx. Weight (Charged) | ~28–30 kg |
| Applications | Large industrial plants, power stations |
6. 22.5 kg CO2 Fire Extinguisher (Trolley Type)
| Specification | Details |
|---|---|
| Capacity | 22.5 kg |
| Fire Rating | 233B / C |
| Cylinder Material | Seamless Mild Steel |
| Working Pressure | 55 bar @ 27°C |
| Test Pressure | 250 bar |
| Discharge Time | 50–60 seconds |
| Discharge Range | 2–8 meters |
| Approx. Weight (Charged) | ~65–70 kg |
| Applications | Airports, chemical plants, high-risk industrial sites |
What Fires Can a CO2 Extinguisher Safely Tackle?
Fire extinguisher CO2 is used almost exclusively in every field to extinguish fires caused by live cables and electrical tools. Nevertheless, you can also utilise them on fires driven by flammable liquids (Class B fires). Moreover, you need to be very clear that no other type of fire extinguisher can extinguish an electrical fire. Likewise, the CO2 extinguisher is the only one that can prevent fire and provide vital protection. Moreover, here we have mentioned some practical solutions for tackling fires involving:
- Flammable Liquids, such as paint, petrol, paraffin, and diesel.
- Computer Equipment.
- Electrical Appliances.
Here we have mentioned some forms of fires where a CO2 portable fire extinguisher should not be used, involving:
- Cooking Oils
- Fat (Such As Chip Pans and Deep Fryers)
- Paper
- Textiles
- Wood
Common Places You’ll Find CO2 Fire Extinguishers
Here is the list of the top twenty places where you can find a portable CO2 fire extinguisher, covering both commercial and industrial settings:
- Server Rooms
- Data Centers
- Electrical Switch Rooms
- Computer Labs
- Industrial Control Rooms
- Telecommunication Rooms.
- Ups Rooms
- Manufacturing Floors
- Chemical Laboratories
- Printing Presses
- Workshops
- Airports
- Hospitals
- Banks
- Power Plants
- Marine Vessels
- Recording Studios
- Elevator Machine Rooms
- Shopping Malls
- Theatres & Cinemas
Effective Ways To Use A CO2 Extinguisher
With no second thought, it is okay to use a fire extinguisher CO2 on fairly contained fires. In addition, the fire is in an enclosed area, so CO2 extinguishers should not be used because they lead to asphyxiation, as carbon dioxide is poisonous at a level of 4%.
Instructions for the operation of a CO2 fire extinguisher are posted on the side of the can. But it’s always best to be aware of them beforehand in case you’re ever in a situation where you need to use one.
- Take out the safety pin.
- Point the CO2 fire extinguisher’s hose at the bottom of the fire – this is crucial because you want to hit the origin of the fire.
- Compress the lever on the extinguisher.
- Sweep the hose of the extinguisher in wide motions with the nozzle directed at the bottom of the fire.
- Keep the hose at the base and not the nozzle opening since the sacking freezing CO2 gas might freeze-burn your skin.
- A portable CO2 fire extinguisher discharges very rapidly, so it should be used only on small fires that can be quickly engulfed.
Imperative Things That You Must Know About CO2 Fire Extinguisher
A CO2 fire extinguisher comes with a lot of precautions that every individual should be familiar with before using it. Check out the vital pointers that we have mentioned below to know what you should keep in mind before using it:
- Extinguisher leaves no post-fire residue
- Ensure to avoid direct skin CO2 contact
- It is not for confined space use
- It is best for Class B & electrical
- It has Short-range discharge capability
It’s Time To Conclude Here!
We hope this blog has provided you with all the precise details and information about the CO2 extinguisher. If you are searching for the CO2 portable fire extinguisher, look no further than Somya Pyrotek Services Pvt. Ltd. We have a wide range of extinguishers that suit your specific needs and preferences. Whether you need 1kg, 4kg, 6kg, or 9kg, we provide fire extinguishers in a range of sizes. Furthermore, as we all know, it is not fire prevention equipment for households or businesses. It is one of the most imperative tools that every industry needs as it is portable, easy to use, and inexpensive.
Nevertheless, if your area is more likely to overheat, remember to have extinguishers available. Therefore, we also offer many other fire prevention tools, such as fire alarms, fire-resistant materials to prevent fires, and more. So, what are you waiting for? Connect with us today and secure your space with the right fire extinguisher CO2 at its best price.
